Technical Facts

"Precision is no coincidence –
it's the result of cutting-edge technology and decades of experience."

For the implementation of all projects we are available to our customers with our team of over 80 highly motivated, experienced engineers and technicians, as well as a production area of more than 3000 m² with an overhead crane.

Of course, we can process all conventional data formats (for example, step, IGES, PTC Creo, dxf, Catia V5, etc.) for transmitting item data. We have 5 ultra-modern CAD workplaces available for the design of mold construction projects.

The extensive and ultra-modern engineering and machine park with around 40 processing machines offers 15 different options for metal processing.

Want to know all the details?
Download our technical factsheet here:

Technical Facts – Rathgeber GmbH

read moreread less
Tool sizes


1,800 x 1,200 mm in X/Y, weight = max. 20 t

Item sizes


1,600 x 1,000 mm in X/Y

Machining sizes

Milling:1,800 x 1,200 x 1,070 mm
Turning diameter:      380 mm CNC / 450 mm manually
Circular grinding:500 x 1,000 mm
Surface and Profile grinding:       1,000 x 600 x 425 mm / 500 x 300 x 150 mm
Deep hole drilling:1,200 x 750 x 990 mm
Wire cutting1,250 x 1,020 x 305 mm
Electrode manufacture:      700 x 700 x 400 mm
Eroding:1,800 x 1,200 x 600 mm
Pilot hole erosion:950 x 600 x 500 mm
Spotting pressing:1,500 x 1,200 x 1,300 mm
Measuring:1,200 x 900 x 550 mm
Sampling:1,700 x 1,500 x 1,480 mm
